Ubiquiti NanoStation M5 150 Mbit/s White Power over Ethernet (PoE)
- 5 GHz
- Maximum data transfer rate: 150 Mbit/s
- IEEE 802.3u
- Power over Ethernet (PoE)
| Features | |
|---|---|
| Networking standards | IEEE 802.3u |
| Frequency band | 4.9 – 5.9 GHz |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 150 Mbit/s |
| 5 GHz | Yes |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
|---|---|
| Power consumption (typical) | 8 W |
| Input current | 0.5 A |
| AC input voltage | 24 V |
| Power over Ethernet (PoE) | Yes |
| Design | |
|---|---|
| Internal | No |
| LED indicators | Yes |
| Product colour | White |
| Antenna | |
|---|---|
| Antenna gain level (max) | 16 dBi |
| Performance | |
|---|---|
| Flash memory | 8 MB |
| Internal memory | 64 MB |
| Processor architecture | MIPS 24Kc |
| Processor model | Qualcomm Atheros |
| Built-in processor | Yes |
| Certificates | |
|---|---|
| Certification | FCC, CE, RoHS |
| Weight & dimensions | |
|---|---|
| Weight | 400 g |
| Height | 294 mm |
| Depth | 31 mm |
| Width | 80 mm |
| Other features | |
|---|---|
| Maximum operating distance | 15000 m |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -30 – 80 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
