TieDex UK TP-Link TL-WPA7617 V1 – powerline adapter – Wi-Fi 5 – wall-pluggable
TP-Link TL-WPA7617 V1 – Powerline adapter 1GbE, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0, IEEE 1901 – Wi-Fi 5 – Dual Band – wall-pluggable
Basic Specifications
- Manufacturer’s Part Number
- TL-WPA7617
- EAN
- 4897098687628
- Product Description
- TP-Link TL-WPA7617 V1 – powerline adapter – Wi-Fi 5 – wall-pluggable
- Model
- TP-Link TL-WPA7617 V1
- Dimensions (WxDxH)
- 6.95 cm x 3.5 cm x 12.41 cm
- Features
- Reset button, LED on/off button, Wi-Fi Auto-Sync, pair button
- Device Type
- Powerline adapter
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, HomePlug AV, HomePlug AV 2.0, IEEE 1901, IEEE 802.11ac
- System Requirements
- Apple MacOS, Linux, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10
- Data Transfer Rate
- 1 Gbps
- Performance
- Maximum data rate (2.4 GHz): 300 Mbps ¦ Maximum data rate (5 GHz): 867 Mbps
- Frequency Band
- 2.4 GHz / 5 GHz
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0, IEEE 1901, IEEE 802.11ac
- Enclosure Type
- Wall-pluggable
- Routing Protocol
- IGMPv2, IGMP, IGMPv3
General
- Device Type
- Powerline adapter
- Enclosure Type
- Wall-pluggable
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0, IEEE 1901, IEEE 802.11ac
- Frequency Band
- 2.4 GHz / 5 GHz
- Data Transfer Rate
- 1 Gbps
- Max Range Indoors
- 300 m
- Performance
- Maximum data rate (2.4 GHz): 300 Mbps ¦ Maximum data rate (5 GHz): 867 Mbps
- Routing Protocol
- IGMPv2, IGMP, IGMPv3
- Encryption Algorithm
- WPA-PSK, 128-bit AES, WPA2-PSK, WEP
- Authentication Method
- Radio Service Set ID (SSID)
- Wi-Fi Rating
- AC1200
- Features
- Reset button, LED on/off button, Wi-Fi Auto-Sync, pair button
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, HomePlug AV, HomePlug AV 2.0, IEEE 1901, IEEE 802.11ac, Plug and Play, RoHS
- Status Indicators
- Port status, power, powerline, 2.4/5 GHz
Dimensions & Weight
- Width
- 6.95 cm
- Depth
- 3.5 cm
- Height
- 12.41 cm
Miscellaneous
- Cables Included
- Network cable
Expansion / Connectivity
- Interfaces
- 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ 1 x HomePlug AV 2.0
Power
- Power Device
- Internal power supply
- Power Consumption Operational
- 6.5 Watt
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 – 90% (non-condensing)
Software / System Requirements
- OS Required
- Apple MacOS, Linux, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10
Line Properties
- Line Coding Format
- OFDM
