Supermicro MBD-M12SWA-TF Socket sWRX8 Extended ATX
- AMD Ryzen™ Threadripper™ PRO 3000WX Series Processor, up to 64 Cores
- Up to 2TB (RDIMM) / 256GB (UDIMM), ECC/Non-ECC, Unbuffered, U-DIMM, R-DIMM, LRDIMM, and 3DS R-DIMM; 3200Mhz in 8 DIMM slots
- ASPEED AST2600 BMC graphics
- 1x 10GBase-T LAN port
- 1 GbE LAN port (shared with IPMI)
| Processor | |
|---|---|
| Compatible processor series | AMD Ryzen Threadripper 1000 Series |
| Processor socket | Socket sWRX8 |
| Processor manufacturer | AMD |
| Memory | |
|---|---|
| Maximum RDIMM memory | 2 TB |
| Unbuffered memory | Yes |
| Supported memory module capacities | 2GB, 4GB, 16GB, 32GB, 64GB, 128GB |
| Maximum internal memory | 2 TB |
| ECC сompatibility | ECC & Non-ECC |
| Memory voltage | 1.2 V |
| Memory channels | Octa-channel |
| Memory slots type | DIMM |
| Number of memory slots | 8 |
| Supported memory types | DDR4-SDRAM |
| Storage controllers | |
|---|---|
| RAID levels | 0, 1, 5, 10 |
| RAID support | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| Graphics | |
|---|---|
| On-board graphics card model | Aspeed AST2600 |
| Internal I/O | |
|---|---|
| Number of COM connectors | 1 |
| TPM connector | Yes |
| Number of SATA III connectors | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| USB 2.0 connectors | 2 |
| Rear panel I/O ports | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| IPMI LAN (RJ-45) port | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Network | |
|---|---|
| LAN controller | Intel® I210-AT |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Features | |
|---|---|
| PC health monitoring | CPU, Fan, LED, Temperature |
| Audio output channels | 7.1 channels |
| Motherboard chipset family | AMD |
| Motherboard form factor | Extended ATX |
| Component for | Server |
| Expansion slots | |
|---|---|
| Number of M.2 (M) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 6 |
| BIOS | |
|---|---|
| BIOS memory size | 256 Mbit |
| BIOS type | AMI |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -5 – 55 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733020 |
