Nvidia ConnectX-6 Dx EN Internal Fiber 100000 Mbit/s
- Wired
- PCI Express 4.0 Fiber
- 100 Gigabit Ethernet 100000 Mbit/s
- Internal Component for: Server
Advanced Networking and Security for the Most Demanding Cloud and Data Center Workloads
NVIDIA® ConnectX®-6 Dx is a highly secure and advanced smart network interface card (SmartNIC) that accelerates mission-critical cloud and data center applications, including security, virtualization, SDN/NFV, big data, machine learning, and storage. ConnectX-6 Dx provides up to two ports of 100Gb/s or a single port of 200Gb/s Ethernet connectivity and is powered by 50Gb/s (PAM4) or 25/10 Gb/s (NRZ) SerDes technology.
ConnectX-6 Dx features virtual switch (vSwitch) and virtual router (vRouter) hardware accelerations delivering orders-of-magnitude higher performance than software-based solutions. ConnectX-6 Dx supports a choice of single-root I/O virtualization (SR-IOV) and VirtIO in hardware, enabling customers to best address their application needs. By offloading cloud networking workloads, ConnectX-6 Dx frees up CPU cores for business applications while reducing total cost-of-ownership.
| Ports & interfaces | |
|---|---|
| PCI version | 4.0 |
| Fiber ports quantity | 2 |
| Fiber optic connector | QSFP56 |
| Interface | Fiber |
| Host interface | PCI Express |
| Connectivity technology | Wired |
| Network | |
|---|---|
| Ethernet interface type | 100 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Maximum data transfer rate | 100000 Mbit/s |
| Design | |
|---|---|
| Form factor | OCP 3.0 |
| Product colour | Green, Grey |
| Component for | Server |
| Internal | Yes |
