Lenovo ThinkSystem SR650 V2 server Rack (2U) Intel Xeon Silver 4310 2.1 GHz 32 GB DDR4-SDRAM 1100 W
- Intel Xeon Silver 4310 (18MB Cache, 2.1GHz)
- 32GB DDR4-SDRAM (1 x 32)
The Lenovo ThinkSystem SR650 V2 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem SR650 V2 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR650 V2 and consider its use in IT solutions.
| Processor | |
|---|---|
| Number of processors installed | 1 |
| Motherboard chipset | Intel C621A |
| Processor cache | 18 MB |
| Processor cores | 12 |
| Processor boost frequency | 3.3 GHz |
| Processor frequency | 2.1 GHz |
| Processor model | 4310 |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor family | Intel Xeon Silver |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 12 TB |
| Memory slots | 32x DIMM |
| ECC | Yes |
| Memory layout (slots x size) | 1 x 32 GB |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 32 GB |
| Storage | |
|---|---|
| Internal drive bays | 8 |
| Supported storage drive interfaces | SAS |
| Optical drive type | No |
| Hot-swap | Yes |
| Supported RAID controllers | 9350-8i |
| RAID support | Yes |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Design | |
|---|---|
| Product colour | Black, Silver |
| Chassis type | Rack (2U) |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows ServerRed Hat Enterprise LinuxSUSE Linux Enterprise ServerVMware ESXi |
| Power | |
|---|---|
| Power supply | 1100 W |
| Operational conditions | |
|---|---|
| Operating altitude | 0 – 3050 m |
| Storage relative humidity (H-H) | 8 – 90% |
| Storage temperature (T-T) | -40 – 60 °C |
| Certificates | |
|---|---|
| 80 PLUS certification | 80 PLUS Titanium |
| General | |
|---|---|
| Product family | ThinkSystem |
| Weight & dimensions | |
|---|---|
| Weight | 38.8 kg |
| Depth | 764 mm |
| Height | 87 mm |
| Width | 445 mm |
| Technical details | |
|---|---|
| Supported storage drives form factor (rear) | 2.5″ |
