Lenovo 4XC7A08237 network card Internal Fiber 25000 Mbit/s
- Wired
- PCI Express 4.0 Fiber
- 25000 Mbit/s
- Internal Component for: Server
The ThinkSystem Broadcom 57412 and 57414 10/25GbE SFP28 Ethernet Adapters are high-performance 25 Gb Ethernet adapters that offers TruFlow intelligent flow processing and support advanced networking technologies including RoCE, SDN, NFV and virtualization. Both 1-port (57412) and 2-port (57414) adapters are offered.
– One Broadcom adapter
– An attached full-height (3U) bracket, and a low-profile (2U) bracket that can be substituted if needed
– Documentation flyer
| Ports & interfaces |
| PCI version |
4.0 |
| Fiber ports quantity |
2 |
| Fiber optic connector |
SFP28 |
| Interface |
Fiber |
| Host interface |
PCI Express |
| Connectivity technology |
Wired |
| Network |
| Maximum data transfer rate |
25000 Mbit/s |
| Design |
| Compatible products |
SR635 V3 (7D9H / 7D9G)SR655 V3 (7D9F / 7D9E)SR645 V3 (7D9D / 7D9C)SR665 V3 (7D9B / 7D9A)SR630 V3 (7D72 / 7D73)SR650 V3 (7D75 / 7D76)SR850 V3 (7D97 / 7D96)SR860 V3 (7D94 / 7D93)SR630 V2 (7Z70 / 7Z71)SR650 V2 (7Z72 / 7Z73)SR670 V2 (7Z22 / 7Z23)SR635 (7Y98 / 7Y99)SR655 (7Y00 / 7Z01)SR645 (7D2Y / 7D2X)SR665 (7D2W / 7D2V)SR850 V2 (7D31 / 7D32)SR860 V2 (7Z59 / 7Z60) |
| Product colour |
Black, Green, Stainless steel |
| Component for |
Server |
| Internal |
Yes |
| System requirements |
| Compatible operating systems |
VMware vSphere Hypervisor (ESXi) 6.7 U3VMware vSphere Hypervisor (ESXi) 7.0VMware vSphere Hypervisor (ESXi) 7.0 U1 VMware vSphere Hypervisor (ESXi) 7.0 U2VMware vSphere Hypervisor (ESXi) 7.0 U3VMware vSphere Hypervisor (ESXi) 8.0 |
| Operational conditions |
| Operating relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-40 – 65 °C |
| Operating temperature (T-T) |
0 – 55 °C |
| Weight & dimensions |
| Height |
63 mm |
| Width |
167 mm |
