Kingston Technology KSM26RS8/8HDI memory module 8 GB 1 x 8 GB DDR4 2666 MHz ECC
- Functionality and operations comply with the DDR4 SDRAM datasheet
- 16 internal banks
- Bi-Directional Differential Data Strobe
- 8 bit pre-fetch
- Supports ECC error correction and detection
- On-Die Termination (ODT)
- Temperature sensor with integrated SPD
- This product is in compliance with the RoHS directive
- Per DRAM Addressability is supported
- Internal Vref DQ level generation is available
- Write CRC is supported at all speed grades
- CA parity (Command/Address Parity) mode is supported
Kingston’s KSM26RS8/8HDI is a 1G x 72-bit (8GB) DDR4-2666 CL19 SDRAM (Synchronous DRAM) registered w/ parity, 1Rx8, ECC, memory module, based on nine 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-2666 timing of 19-19-19 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
| Features |
| JEDEC standard |
Yes |
| Lead plating |
Gold |
| Country of origin |
Taiwan |
| Programming power voltage (VPP) |
2.5 V |
| Row active time |
32 ns |
| Refresh row cycle time |
350 ns |
| Row cycle time |
46.25 ns |
| Module configuration |
1024M x 72 |
| Memory voltage |
1.2 V |
| CAS latency |
19 |
| ECC |
Yes |
| Memory form factor |
288-pin DIMM |
| Component for |
PC/Server |
| Memory clock speed |
2666 MHz |
| Internal memory type |
DDR4 |
| Memory layout (modules x size) |
1 x 8 GB |
| Internal memory |
8 GB |
| Operational conditions |
| Storage temperature (T-T) |
-55 – 100 °C |
| Operating temperature (T-T) |
0 – 85 °C |
| Technical details |
| Compliance certificates |
RoHS |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
