j5create JVA02 Live Capture Adapter HDMI™ to USB-C™ with Power Delivery, Black
- Uncompressed mode gives excellent video quality and reduces CPU loading
- Power Delivery 3.0 allows you to live stream without interruption
- Professional listening and microphone mixer function
- Low power consumption with high performance
- Includes camera screws to attach to cold shoe adapter
- Full HD video and audio high-performance record/playback through USB-C™ 3.1
- Capture resolution up to 1080p @ 60 fps
- Microphone input & Audio output
- 3 audio modes: Mic/ HDMI™/ Mix
- Aluminum design
Perfect for live streaming — The JVA02 is a lightweight, stylish and powerful HDMI™ capture card. It consumes very low power, yet can capture 1080p with 60 frames of uncompressed video under USB™ 3.0. It can be broadcast continuously with three mixing modes and Power Delivery 3.0. Connect the JVA02 to your cold shoe adapter on your camera for the perfect combination of ease-of-use and functionality.
| Performance | |
|---|---|
| Special features | Power Delivery 3.0 lets you stream live without interruptionProfessional listening and live audio mixing with built-in audio mixer |
| Country of origin | Taiwan |
| Housing material | Aluminium |
| Plug and Play | Yes |
| Supported aspect ratios | 16:9 |
| Cable length | 1 m |
| Interface | USB Type-C 3.1 Gen1 |
| Video capture resolution (max) | 1920 x 1080 pixels |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) |
| Internal | No |
| Product colour | Black |
| Video | |
|---|---|
| Supported video modes | 480i, 480p, 720i, 720p, 1080i, 1080p |
| Maximum frame rate | 60 fps |
| Analog signal format system | Not supported |
| Audio | |
|---|---|
| Supported audio channels | 2 |
| File formats | |
|---|---|
| Video compression formats | AVC, H.264, M-JPEG, MP4 |
| Ports & interfaces | |
|---|---|
| Headphone outputs | 1 |
| HDMI in | 1 |
| HDMI ports quantity | 1 |
| USB ports quantity | 2 |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-A, USB Type-C |
| USB port | No |
| Power | |
|---|---|
| Power consumption | 2.5 W |
| Output voltage | 20 V |
| Output current | 0.5 A |
| Power supply type | USB |
| Software | |
|---|---|
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Mac compatibility | Yes |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -10 – 65 °C |
| Operating temperature (T-T) | 0 – 40 °C |
| Technical details | |
|---|---|
| Warranty period | 2 year(s) |
| Other features | |
|---|---|
| Inner carton dimensions (W x D x H) | 105 x 150 x 160 mm |
| Compatible operating systems | Windows® 7 or later (Driver installation is required on Windows® 7) |
| Maximum data transfer rate | 5000 Mbit/s |
| Master (outer) case width | 225 mm |
| Master (outer) case height | 180 mm |
| Weight & dimensions | |
|---|---|
| Package length | 9.5 cm |
| Weight | 51.5 g |
| Height | 64.5 mm |
| Depth | 17.5 mm |
| Width | 133.8 mm |
| Packaging content | |
|---|---|
| Packaging content | 1 x JVA02 Live Capture UVC HDMI™ to USB™ Video Capture, 2 x Cold shoe adapter, 1 x USB-C™ 2.0 to USB-C™ cable, 1 x USB-C™ 3.0 to USB™ Type-A cable, 1 x User Manual, 1 x Quick Installation Guide |
| Manual | Yes |
| Quick installation guide | Yes |
| Cables included | USB Type-A to USB Type-C, USB Type-C to USB Type-C |
| Packaging data | |
|---|---|
| Package type | Box |
| Package height | 25 mm |
| Package width | 145 mm |
| Package depth | 95 mm |
| Package weight | 148.5 g |
| Logistics data | |
|---|---|
| Products per shipping (inner) case | 5 pc(s) |
| Master (outer) case gross weight | 3.7 kg |
| Master (outer) case GTIN (EAN/UPC) | 24712795082986 |
| Products per master (outer) case | 20 pc(s) |
| Master (outer) case length | 321 mm |
| Shipping (inner) case gross weight | 810 g |
