Intel Xeon E3-1270V2 processor 3.5 GHz 8 MB Smart Cache
- Intel® Xeon® E3 V2 Family E3-1270V2 3.5 GHz
- 8 MB Smart Cache LGA 1155 (Socket H2)
- Processor cores: 4 22 nm 64-bit 69 W
- Maximum internal memory supported by processor: 32 GB DDR3-SDRAM
Intel® Xeon® Processor E3 Family
Intel® Xeon® processor E3 family-based servers give you smarter control of the things that matter to your business—increased sales, improved margins, and reduced risk. As your business becomes more sophisticated, so do your technology needs—real servers give you benefits that a desktop PC used as a server cannot.
The Intel® Xeon® processor E3-1200 v2 product family offers up to 32% more energy efficient performance than previous generation Intel® Xeon® processor-based servers.
A number of technologies have been added or upgraded to improve I/O bandwidth, gain faster access to commonly used programs and files, allow applications to run faster, increase data throughput, and improve the performance of disc-intensive retrieval applications.
Built-in, advanced security features help you deflect catastrophic security breaches, and redundant storage capabilities protect your business data in the event of a hard drive failure.
The Intel® Xeon® processor platform is built for all day, every day reliability. Centralized data backup and critical security updates further help reduce the risk of costly downtime.
Servers featuring Intel® Xeon® processors have intelligent performance that adapts to your needs, giving you the reliability you need today with plenty of room to grow for tomorrow. With built-in 24/7 dependability and advanced security features, Intel®-based servers help you avoid costly business interruptions and potentially catastrophic security breaches. Spend your time focused on your business—respond more quickly to customers, opportunities, and trends—with Intel®-based servers, a smart investment in your business future.
| Processor | |
|---|---|
| Processor ARK ID | 65727 |
| Processor code | SR0P6 |
| Processor codename | Ivy Bridge |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| CPU multiplier (bus/core ratio) | 35 |
| Bus type | DMI |
| Stepping | E1 |
| Compatible chipsets | Intel® C202, Intel® C204, Intel® C206, Intel® C216 |
| Thermal Design Power (TDP) | 69 W |
| L3 cache speed | 3.50 GHz |
| Processor cache type | Smart Cache |
| Processor cache | 8 MB |
| Processor boost frequency | 3.9 GHz |
| Processor operating modes | 64-bit |
| System bus rate | 5 GT/s |
| Processor threads | 8 |
| Processor series | Intel Xeon E3-1200 v2 |
| Component for | Server/workstation |
| Cooler included | No |
| Box | No |
| Processor lithography | 22 nm |
| Processor socket | LGA 1155 (Socket H2) |
| Processor cores | 4 |
| Processor base frequency | 3.5 GHz |
| Processor model | E3-1270V2 |
| Processor family | Intel® Xeon® E3 V2 Family |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 1333,1600 MHz |
| Memory types supported by processor | DDR3-SDRAM |
| Maximum internal memory supported by processor | 32 GB |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Export Control Classification Number (ECCN) | 5A992C |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| CPU configuration (max) | 1 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX |
| PCI Express configurations | 1×16, 1×4, 2×8, 1×8, 3×4 |
| PCI Express slots version | 3.0 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor special features | |
|---|---|
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Demand Based Switching | Yes |
| Intel Clear Video Technology | No |
| Intel TSX-NI | No |
| Intel Enhanced Halt State | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel TSX-NI version | 0.00 |
| Conflict-Free processor | No |
| Intel® Transactional Synchronization Extensions | No |
| Intel® Turbo Boost Technology 2.0 frequency | 3.9 GHz |
| Intel® Wireless Display (Intel® WiDi) | No |
| Intel® Insider™ | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Fast Memory Access | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | No |
| Intel Flex Memory Access | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Smart Cache | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel FDI Technology | No |
| Intel Dual Display Capable Technology | No |
| General | |
|---|---|
| Product family | Xeon |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8542310001 |
| Technical details | |
|---|---|
| Bus bandwidth | 5 |
| Bus type units | GT/s |
| Processor brand name | Intel Xeon |
| Last change | 63903513 |
| Product family | Intel Xeon Processor E3 v2 Family |
| Launch date | Q2’12 |
| Status | Discontinued |
| Maximum memory | 32.77 GB |
| Bus speed | 5 GT/s |
| Processor cache | 8192 KB |
| Supported memory types | DDR3-SDRAM |
| Product type | Processor |
| Packaging data | |
|---|---|
| Package type | Retail box |
| Weight & dimensions | |
|---|---|
| Processor package size | 37.5 x 37.5 mm |
| Other features | |
|---|---|
| Maximum internal memory | 32.77 GB |
| Compatibility | Intel S1200KP, S1200BTSR, S1200KPR, S1200BTLR, R1304BTLSHBNR, R1304BTLSFANR, R1304BTSSFANR, P4304BTLSHCNR, P4304BTLSFCNR, P4304BTSSFCNR |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
