DELL PowerEdge R350 server 600 GB Rack (1U) Intel Xeon E E-2314 2.8 GHz 16 GB DDR4-SDRAM 600 W
- No OS
- Intel Xeon E-2314 (8MB Cache, 2.8GHz)
- 16GB (3200MHz) DDR4-SDRAM (1 x 16) & 600GB HDD
- iDRAC9 Express 15G
Powerful single processor server
Address evolving compute demands with an easy to manage rack server designed for businesses looking for affordable enterprise features.
| Processor |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Number of processors installed |
1 |
| Processor cache |
8 MB |
| Processor boost frequency |
4.5 GHz |
| Processor frequency |
2.8 GHz |
| Processor model |
E-2314 |
| Processor family |
Intel Xeon E |
| Processor manufacturer |
Intel |
| Memory |
| Maximum internal memory |
64 GB |
| Memory data transfer rate |
3200 MT/s |
| Memory slots |
4x DIMM |
| ECC |
Yes |
| Memory clock speed |
3200 MHz |
| Memory layout (slots x size) |
1 x 16 GB |
| Buffered memory type |
Unregistered (unbuffered) |
| Internal memory type |
DDR4-SDRAM |
| Internal memory |
16 GB |
| Storage |
| Optical drive type |
No |
| Hot-Plug support |
Yes |
| Supported RAID controllers |
PERC H355 |
| RAID support |
No |
| HDD size |
2.5″ |
| HDD speed |
10000 RPM |
| HDD interface |
Serial Attached SCSI (SAS) |
| HDD capacity |
600 GB |
| Number of HDDs installed |
1 |
| Total storage capacity |
600 GB |
| Graphics |
| On-board graphics card model |
Not available |
| Network |
| LAN controller |
Broadcom 5720 |
| Ethernet LAN |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
| VGA (D-Sub) ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| Expansion slots |
| PCI Express x16 slots |
1 |
| PCI Express x8 slots |
1 |
| Design |
| Rack mounting |
Yes |
| Rack rails |
Yes |
| Product colour |
Black |
| Chassis type |
Rack (1U) |
| Performance |
| Remote administration |
iDRAC9 Express 15G |
| Software |
| Compatible operating systems |
Canonical Ubuntu Server LTSCitrix HypervisorMicrosoft Windows Server with Hyper-VRed Hat Enterprise LinuxSUSE Linux Enterprise Server |
| Operating system installed |
No |
| Processor special features |
| CPU configuration (max) |
1 |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Power |
| Power cable current |
10 A |
| Power cable connector 2 |
C14 coupler |
| Power cable connector 1 |
C13 coupler |
| Power cable length |
2 m |
| Number of main power supplies |
2 |
| Power supply |
600 W |
| Redundant power supply (RPS) support |
Yes |
| Operational conditions |
| Non-operating altitude |
0 – 12000 m |
| Operating altitude |
0 – 3048 m |
| Storage relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-40 – 65 °C |
| General |
| Product family |
PowerEdge |
| Carbon footprint |
| Total carbon footprint (kg of CO2e) |
2410 |
| Total carbon emissions, standard deviation (kg of CO2e) |
1160 |
| Carbon emissions, manufacturing (kg of CO2e) |
451 |
| Carbon emissions, logistics (kg of CO2e) |
107 |
| Carbon emissions, energy usage (kg of CO2e) |
1840 |
| Carbon emissions, end-of-life (kg of CO2e) |
17 |
| Total carbon emissions, w/o use phase (kg of CO2e) |
575 |
| PAIA version |
1.3.2, 2022 |
| Logistics data |
| Harmonized System (HS) code |
84714100 |
| Weight & dimensions |
| Height |
428 mm |
| Width |
434 mm |
| Other features |
| Data transfer rate |
12 Gbit/s |
| Bytes per sector |
512n |
