D-Link DWL-6610APE wireless access point 1200 Mbit/s White Power over Ethernet (PoE)
- 2.4 GHz
- 5 GHz
- Maximum data transfer rate: 1200 Mbit/s
- IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af
- AES, HTTPS, SSH, SSID, TKIP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
- Power over Ethernet (PoE)
- Antennas quantity: 4 Detachable antenna
Performance without Compromise
The DWL-6610APE is an affordable, Unified Wireless AC1200 Access Point, enabling businesses of all sizes create the fastest wireless network possible. With a sleek and stylish design, the DWL-6610APE can be discreetly deployed anywhere.
Wireless AC 1200
Maximum combined wireless speed of 1200 Mbps.
Broadcast on 32 SSIDs Simultaneously
Supports up to 32 SSIDs, 16 per radio, including station isolation.
Dual Band
Supports both 2.4Ghz and 5Ghz bands simultaneously.
Unified Wireless
Access points can be managed by unified wireless controller.
Smart Design
The DWL-6610APE can be mounted easily onto any wall or ceiling without looking out of place in an office or home. Enclosed in a plenum-rated UL2043 certified housing, the DWL-6610APE adheres to strict fire codes for placement in air passageways.
Band Steering technology
With band steering, the DWL-6610APE detects whether or not the wireless client is dual-band capable, and if so, it pushes the client to connect to the less congested 5 Ghz band. It does this by actively blocking the client’s attempts to associate with the 2.4 Ghz network.
Versatility Built as standard
Whether you intend to use a single Access Point or roll out a large corporate network, the DWL-6610APE coupled with a D-Link Wireless Controller or Unified Switch makes managing your wireless network simple.
Secure and Green Design
The DWL-6610APE has a wireless scheduler feature, which turns off wireless functionality when it isn’t needed, saving power and increasing network security.
Fast Seamless Roaming
Combining the DWL-6610APE with a Unified Wireless Switch or Controller allows you to create a wireless network that enables people to move freely around a building without losing connectivity.
Management platforms
D-Link’s Unified Wireless Access Points can be managed using a D-Link Wireless Controller or Unified Switch.
DWL-6610APE Management platforms
Simultaneous Dual-Band
Supports up to 867 Mbps 2×2 MIMO for the 5Ghz band and up to 300Mbps 2×2 MIMO for the 2.4Ghz band
| Features | |
|---|---|
| Quality of Service (QoS) support | Yes |
| VLAN support | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Channels quantity | 165 channels |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af |
| Frequency band | 2.4 – 2.4835, 5.15 – 5.85 GHz |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 1200 Mbit/s |
| 5 GHz | Yes |
| 2.4 GHz | Yes |
| Security | |
|---|---|
| Number of SSID supported | 32 |
| MAC address filtering | Yes |
| Security algorithms | AES, HTTPS, SSH, SSID, TKIP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise |
| Management features | |
|---|---|
| Web-based management | Yes |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
|---|---|
| Power consumption (max) | 10.2 W |
| Output current | 1.5 A |
| Output voltage | 12 V |
| Power over Ethernet (PoE) | Yes |
| Design | |
|---|---|
| Internal | No |
| LED indicators | Yes |
| Housing material | Plastic |
| Product colour | White |
| Placement | Table |
| Antenna | |
|---|---|
| Antenna gain level (max) | 4 dBi |
| Antennas quantity | 4 |
| Antenna features | Detachable antenna |
| Technical details | |
|---|---|
| Shipping (inner) case length | 56.5 cm |
| Shipping (inner) case width | 34.3 cm |
| Shipping (inner) case height | 27.5 cm |
| Shipping (inner) case net weight | 6.89 kg |
| Products per shipping (inner) case | 6 pc(s) |
| Pallet gross weight (air) | 212.5 kg |
| Master (outer) cases per pallet (air) | 24 pc(s) |
| Products per pallet (air) | 144 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 123.5 cm |
| Pallet gross weight (sea) | 347.3 kg |
| Master (outer) cases per pallet (sea) | 42 pc(s) |
| Products per pallet (sea) | 252 pc(s) |
| Pallet height (sea) | 2.06 m |
| Shipping (inner) case gross weight | 7.79 kg |
| Certificates | |
|---|---|
| Certification | CE, FCC, IC, cUL+UL, LVD, RCM, NCC, BSMI, UL2043 |
| Weight & dimensions | |
|---|---|
| Weight | 476 g |
| Height | 39 mm |
| Width | 205 mm |
| Packaging data | |
|---|---|
| Package weight | 1.15 kg |
| Package height | 90 mm |
| Package depth | 235 mm |
| Package width | 243 mm |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 – 95% |
| Storage temperature (T-T) | -20 – 65 °C |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
