Citizen CL-S521 label printer Direct thermal 203 150 mm/sec Wired
- Direct thermal
- 203
- Maximum printing width: 18.1 cm Print speed: 150 mm/sec
- Connectivity technology: Wired
- 3.6 kg
Durable all-metal mechanism
– Citizen’s Hi-Lift™ design
– Easy media loading, durable design and long-life printing
Cross-Emulation
– Automatically switch between Zebra® ZPL® and Datamax®
– Both emulations are standard on all printers
– Use the BASIC Interpreter for specialist applications
Internal Power Supply
– For the ultimate in reliability and hassle-free operation.
Internal Networking Options
– Optional Ethernet and Wireless LAN interfaces
– Easily installed inside the printer’s case avoiding accidental damage.
Internal 5-inch (125mm) media capacity
– Large capacity media holder inside the printer.
– If that isn’t enough, an external 8-inch (200mm) holder is available.
Wide range of ribbon options
– Uses standard 360 metre ribbons on 1-inch cores
– Inside and outside wound with ARCP™ ribbon control technology
Fast print speed
– With up to 150 mm/s (6ips) on the CL-S521 and CL-S621 in DT
300 dpi version and option
– Designed for logos, pictures and to produce EAN compliant barcodes
Printing | |
---|---|
Maximum printing width | 18.1 cm |
Print speed | 150 mm/sec |
Maximum resolution | 203 |
Colour | No |
Print technology | Direct thermal |
Paper handling | |
---|---|
Maximum media length | 162.6 cm |
Media thickness | 0.0635 – 0.254 mm |
Supported paper width | 12.5 – 118.1 mm |
Maximum roll diameter | 12.5 cm |
Core diameter | 2.5 cm |
Media thickness (imperial) | 0.0025 – 0.01″ |
Supported paper width (imperial) | 0.50 – 4.65″ |
Ports & interfaces | |
---|---|
Optional connectivity | Ethernet |
Standard interfaces | USB 1.1, Serial |
RS-232 interface | Yes |
RS-232 ports | 1 |
Parallel ports quantity | 1 |
Wi-Fi | No |
Ethernet LAN | No |
Connectivity technology | Wired |
Performance | |
---|---|
Flash memory | 4 MB |
Internal memory | 16 MB |
Design | |
---|---|
Housing material | Metal, Plastic |
Display | No |
Built-in display | No |
Product colour | Grey |
System requirements | |
---|---|
Compatible operating systems | Windows 7/XP/2003/2008/Vista |
Weight & dimensions | |
---|---|
Weight | 3.6 kg |
Height | 183 mm |
Depth | 289 mm |
Width | 231 mm |
Other features | |
---|---|
Emulations | Datamax I, DMX400, ZPL-II |
Form factor | desktop |
