Cisco Intel Xeon Gold 6544Y processor 3.6 GHz 45 MB
- Intel® Xeon® Gold 6544Y 3.6 GHz
- 45 MB LGA 4677 (Socket E)
- Processor cores: 16 64-bit 270 W
- Maximum internal memory supported by processor: 4 TB DDR5-SDRAM
The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
| Processor | |
|---|---|
| Thermal Design Power (TDP) | 270 W |
| Processor cache | 45 MB |
| Low priority core frequency | 3.5 GHz |
| Low priority cores | 12 |
| High priority core frequency | 3.7 GHz |
| High priority cores | 4 |
| Processor boost frequency | 4.1 GHz |
| Processor operating modes | 64-bit |
| Intel® UPI Speed | 20 GT/s |
| Processor threads | 32 |
| Processor series | Intel Xeon Gold 6000 Series |
| Processor socket | LGA 4677 (Socket E) |
| Processor cores | 16 |
| Processor base frequency | 3.6 GHz |
| Processor model | 6544Y |
| Processor generation | Intel Xeon Scalable 5th Gen |
| Processor family | Intel® Xeon® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Octa-channel |
| Memory clock speeds supported by processor | 5200 MHz |
| Memory types supported by processor | DDR5-SDRAM |
| Maximum internal memory supported by processor | 4 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Scalability | 2S |
| Supported instruction sets | AMX, AVX, AVX 2.0, AVX-512, SSE4.2 |
| PCI Express slots version | 5.0 |
| Maximum number of PCI Express lanes | 80 |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel® Speed Select Technology – Turbo Frequency | Yes |
| Intel® Speed Select Technology – Core Power | Yes |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® Data Streaming Accelerator (DSA) | 1 |
| Intel® Total Memory Encryption – Multi Key | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Speed Select Technology – Base Frequency (Intel® SST-BF) | Yes |
| Intel® OS Guard | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Boot Guard | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Maximum Enclave Size Support for Intel® SGX | 512 GB |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Operational conditions | |
|---|---|
| Tcase | 75 °C |
| DTS Max | 103 °C |
| Technical details | |
|---|---|
| Number of UPI links | 3 |
| Package carrier | E1B |
